Goodmind DTA 900
DTV Converter Box
The DTA900 is a user friendly Digital to Analog TV converter. It’s not only designed for the NTIA coupon eligible converter box (CECB) program but it’s also the best choice to enjoy digital programs without changing your TV set!
The set-top-box can convert all broadcast digital format programs to an analog SD output. All free to air digital programs can be viewed on an analog TV set.
Connect the antenna to the F-type connector on the rear of the unit. The antenna can be mounted on the roof or another appropriate location. It should be aimed towards local DTV broadcast stations for best reception. DTV stations broadcast on both VHF (Ch2 - Ch13) and UHF (Ch14 - Ch69) channels. Make sure to use an antenna that works at the desired frequencies so the converter box can pick up all available DTV broadcasts on those channels.
Features:
Digital Terrestrial receiver delivers free over-the-air digital television signals for an analog LCD television or computer monitor or a traditional CRT TV set.
MPEG-2 Digital & Full ATSC Compliant for 18 ATSC formats, including 180i, 720p and 480p, plus standard 480i.
Selectable picture aspect ratios for 4:3 and 16:9 TV screens.
Support for closed-caption information.
Support English, French, Spanish 3 OSD language.
Support RF Modulator output on channels 3 or 4.
Intuitive signal-strength indicator shows the strength of the incoming signal.
Parental control keeps children from being exposed to undesirable material.
Plug-&-Play design for easy connection to a TV or monitor.
Specifications:
Frequency Range
Channels 2-13 (VHF), 14-69 (UHF)
Compatible input signals
ATSC format (VSB modulation) digital TV signals
Input connections
F-type, RF input, IEC 169-24, 75 ohms
Output connections
1 RCA Composite video Jack (480i)
RCA Audio Right / Left Jacks
F Modulator output
F-type, RF input
IEC 169-24
75 ohms channel 3 or 4 switch
Power
SMPS, 120VAC/60Hz, 10W
Energy Standards
Uses no more than two watts of electricity in the sleep state
User can disable the “automatic switching to sleep state”
User can adjust the default time period from 4 hours to some other value
Remote control
Full function remote control included
Dimensions
Size: 21.0” W x 14.5” D x 4.0” H
Weight
Around 1.1 Kg/2.5lbs
