ComponexX CX-900A
DTV Converter Box

ComponexX CX-900A

General Features:

  • Analog Pass-Through
  • Muti-language OSD (English, French, Spanish)
  • Channel Display Capability
  • Closed Captioning
  • Emergency Alert System (EAS)
  • Parental Controls (V-Chip)
  • Signal Strength Indicator
  • Power LED Indicator
  • Energy Star Standards



    Specifications:

    RF Input:

  • Demodulation: 8VSB
  • Frequency Range: 54 – 860 MHz
  • Connector: F-Type x 1

    RF Output:

  • Signal Type: NTSC
  • Connector: F-Type x 1

    Video Output:

  • Signal Type: NTSC
  • Impedance: 75 Ù
  • Output Level: 1Vp-p
  • Connector: RCA x 1

    Audio Output:

  • Output: Left & Right channel
  • Impedance: 600 Ù max.
  • Output Level: 2Vrms±10%@0dBFS
  • Connector: RCA x 1 set

    Front Panel:

  • IR Receiver
  • 3 Keys Function Control
  • Status LED (Power and standby)

    Remote Control:

  • 26 Keys Remote Control

    Power Consumption:

  • Operation: 8W max.
  • Standby: <1.3 W

    Dimensions:

  • W x D x H (mm) 175 x 135 x 33

    Weight:

  • Unit (g) 445.6

    Power Adaptor:

  • Input: 100-240 VAC, 50/60Hz or 100-120 VAC, 50/60 Hz
  • Output: 5V, 1.5A

    Accessories:

  • Remote Control with batteries included
  • Owner’s Manual (English and Spanish)
  • RF Cable provided
  • AC Power Adapter

    Manufacturers specifications are subject to change without notice.
