AMTC AT-2016 DTV Converter Box
AMTC AT-2016 User Manual
Features
Smart Antenna
interface
ATSC Tuner
Software upgrade
ATSC Tuner Range
Channels 2-6 VHF Low: 54MHz to 88MHz
Channels 7-13 VHF High: 174 MHz to 216MHz
Channels 14-69 UHF: 470MHz to 806MHz
RF Input
75 ohm for VHF and UHF Antenna
RF Output
NTSC, 75ohm Channel 3 or 4
Composite Video Outputs
RCA Connection
Audio Outputs
RCA Stereo Left/Right
Picture Display Formats
4:3 with center cut-out of the 16:9
Letterbox 16:9
Full or Partially zoomed output
General Features
Channel Display Capability
PSIP Processing (EPG included)
Closed Captioning
Emergency Alert System (EAS)
Parental Controls (V-Chip)
Signal Strength Indicator
Power Indicator
Power Supply:
Input Voltage: 100 - 240V~ 50/60Hz
Power Consumption: Maximum 8W,Standby <1W.
Service:
Software upgrade through RS-232 port: 9 pin D-Sub type
Accessories
Remote Control with batteries included (NEC protocol)
Owner’s Manual
RF Cable provided
Manufacturers specifications are subject to change without notice.
